Water level detection.
The Autonomous Overflow Detector will detect the presence of water (or any conductive fluid) above a threshold (ON/OFF state). The detection area is clearly marked on the case by 2 white stripes which allows a precise installation. The user will simply position the detection area at the threshold level required.
A capacitive measure will detect water on the case surface. Note that the measuring system is located inside the case. In order to improve their accuracy, the capacitive measurements are temperature compensated
The advantage of the capacitive technology is the fact that there is no direct contact between the detection system and the environment (which is not the case of conductive systems). Mechanical systems (floaters), are often failing due to clogging, impacts or foreign objects.
HF communication and configuration
Thanks to the programming kit you can set up on site the overflow detector by radio. You will download the same way all stored data from its internal logger.
This kit includes the software Avelour.
Communication GSM / GPRS / 3G / SIGFOX
The Overflow detector LSC connects to an IJINUS sensor or data logger via radio that sends data and alerts by GSM /GPRS / 3G / Sigfox to SCADA software.
Autonomous and wireless, there is no more risk of damaged cable during immersion or cut by rodents. Radio communication is just handy and safer for the fitter who remains out of a dangerous area.
